Click to EnlargeBrake Drum
$122.81 each
Raybestos: 8027
OE Number: 6260588
Product Number: BD8851
PRODUCT DESCRIPTION
Position: Rear Brake Drum
Brake Drum
SRW 383mm
| Part Label: | Brake Drum |
| Bolt Holes: | 8 |
| Bolt Hole Diameter (mm): | 15.50 |
| Outside Diameter (mm): | 383.00 |
| Outside Diameter (in): | 15.08 |
| Inside Diameter (mm): | 330.20 |
| Inside Diameter (in): | 13.00 |
| Center Hole Diameter (mm): | 116.84 |
| Center Hole Diameter (in): | 4.60 |
| Product Depth (mm): | 121.00 |
| Product Depth (in): | 4.76 |
| Product Height (mm): | 132.00 |
| Product Height (in): | 5.20 |
| Maximum Drum Discard Diameter (mm): | 332.50 |
| Mounting Bolt Circle Diameter(mm): | 165.10 |
| Actual Weight (KG): | 19.000 |
| Actual Weight (lbs): | 41.89 |
| Part Description: | Brake Drum |
| F/R: | Rear |
