Click to EnlargeBrake Drum
$38.97 each
Raybestos: 9458
OE Number: 42610SM4010
Product Number: BD3528
PRODUCT DESCRIPTION
Position: Rear Brake Drum
Brake Drum
| Part Label: | Brake Drum |
| Bolt Holes: | 4 |
| Bolt Hole Diameter (mm): | 12.80 |
| Outside Diameter (mm): | 268.00 |
| Outside Diameter (in): | 10.55 |
| Inside Diameter (mm): | 220.00 |
| Inside Diameter (in): | 8.66 |
| Center Hole Diameter (mm): | 64.10 |
| Center Hole Diameter (in): | 2.52 |
| Product Depth (mm): | 54.00 |
| Product Depth (in): | 2.13 |
| Product Height (mm): | 60.00 |
| Product Height (in): | 2.36 |
| Maximum Drum Discard Diameter (mm): | 221.00 |
| Mounting Bolt Circle Diameter(mm): | 114.30 |
| Actual Weight (KG): | 5.750 |
| Actual Weight (lbs): | 12.68 |
| Part Description: | Brake Drum |
| F/R: | Rear |
