Click to EnlargeBrake Drum
$67.54 each
Raybestos: 9779
Product Number: BD35116
PRODUCT DESCRIPTION
Position: Rear Brake Drum
Brake Drum
6 holes
| Part Label: | Brake Drum |
| Bolt Holes: | 6 |
| Bolt Hole Diameter (mm): | 14.40 |
| Outside Diameter (mm): | 306.10 |
| Outside Diameter (in): | 12.05 |
| Inside Diameter (mm): | 254.00 |
| Inside Diameter (in): | 10.00 |
| Center Hole Diameter (mm): | 108.00 |
| Center Hole Diameter (in): | 4.25 |
| Product Depth (mm): | 66.80 |
| Product Depth (in): | 2.63 |
| Product Height (mm): | 73.30 |
| Product Height (in): | 2.89 |
| Nominal Thickness (mm): | 254.10 |
| Nominal Thickness (in): | 10.00 |
| Discard Thickness (mm): | 256.00 |
| Discard Thickness (in): | 10.08 |
| Maximum Drum Discard Diameter (mm): | 256.00 |
| Mounting Bolt Circle Diameter(mm): | 139.70 |
| Actual Weight (KG): | 9.500 |
| Actual Weight (lbs): | 20.94 |
| Part Description: | Brake Drum |
| F/R: | Rear |
This product fits the following vehicles: Does not fit your vehicle? Click here to find parts for you
