Click to EnlargeBrake Drum
$72.70 each
Raybestos: 9753
OE Number: 4243108021
Product Number: BD35106
PRODUCT DESCRIPTION
Position: Rear Brake Drum
Brake Drum
5 holes
| Part Label: | Brake Drum |
| Bolt Holes: | 5 |
| Bolt Hole Diameter (mm): | 14.70 |
| Outside Diameter (mm): | 305.60 |
| Outside Diameter (in): | 12.03 |
| Inside Diameter (mm): | 253.90 |
| Inside Diameter (in): | 10.00 |
| Center Hole Diameter (mm): | 62.00 |
| Center Hole Diameter (in): | 2.44 |
| Product Depth (mm): | 67.10 |
| Product Depth (in): | 2.64 |
| Product Height (mm): | 73.70 |
| Product Height (in): | 2.90 |
| Nominal Thickness (mm): | 253.90 |
| Nominal Thickness (in): | 10.00 |
| Discard Thickness (mm): | 256.00 |
| Discard Thickness (in): | 10.08 |
| Maximum Drum Discard Diameter (mm): | 256.00 |
| Mounting Bolt Circle Diameter(mm): | 114.30 |
| Actual Weight (KG): | 10.820 |
| Actual Weight (lbs): | 23.85 |
| Part Description: | Brake Drum |
| F/R: | Rear |
