Click to EnlargeOEM Replacement Brake Rotor
$32.80 each
Raybestos: 96343
OE Number: 4351235200
Product Number: BR31055
PRODUCT DESCRIPTION
Position: Front OEM Replacement Brake Rotor
Brake Rotor
| Part Label: | Brake Rotor |
| Bolt Holes: | 6 |
| Bolt Hole Diameter (mm): | 10.60 |
| Outside Diameter (mm): | 290.60 |
| Outside Diameter (in): | 11.44 |
| Inside Diameter (mm): | 178.30 |
| Inside Diameter (in): | 7.02 |
| Center Hole Diameter (mm): | 100.10 |
| Center Hole Diameter (in): | 3.94 |
| Product Height (mm): | 65.70 |
| Product Height (in): | 2.59 |
| Nominal Thickness (mm): | 25.00 |
| Nominal Thickness (in): | 0.98 |
| Discard Thickness (mm): | 23.00 |
| Discard Thickness (in): | 0.91 |
| Mounting Bolt Circle Diameter(mm): | 127.00 |
| Mounting Bolt Hole Circle Diameter (in): | 5.00 |
| Actual Weight (KG): | 7.320 |
| Actual Weight (lbs): | 16.14 |
| Part Description: | Brake Rotor |
| F/R: | Front |
