Click to EnlargeBrake Drum
$51.28 each
Raybestos: 97824
OE Number: 5CO.609.617A
Product Number: BD35151
PRODUCT DESCRIPTION
Position: Rear Brake Drum
Brake Drum
| Part Label: | Brake Drum |
| Bolt Holes: | 5 |
| Bolt Hole Diameter (mm): | 15.80 |
| Outside Diameter (mm): | 290.00 |
| Outside Diameter (in): | 11.42 |
| Inside Diameter (mm): | 230.00 |
| Inside Diameter (in): | 9.06 |
| Center Hole Diameter (mm): | 65.00 |
| Center Hole Diameter (in): | 2.56 |
| Product Depth (mm): | 58.30 |
| Product Depth (in): | 2.30 |
| Product Height (mm): | 65.00 |
| Product Height (in): | 2.56 |
| Maximum Drum Discard Diameter (mm): | 231.50 |
| Mounting Bolt Circle Diameter(mm): | 112.00 |
| Actual Weight (KG): | 6.880 |
| Actual Weight (lbs): | 15.17 |
| Part Description: | Brake Drum |
| F/R: | Rear |
