Click to EnlargeBrake Drum
$67.19 each
OE Number: 6826-9703-AA
Product Number: BD576104
PRODUCT DESCRIPTION
Position: Rear Brake Drum
Brake Drum
| Part Label: | Brake Drum |
| Bolt Holes: | 5+3 |
| Bolt Hole Diameter (mm): | 13.20 |
| Outside Diameter (mm): | 302.00 |
| Outside Diameter (in): | 11.89 |
| Inside Diameter (mm): | 254.00 |
| Inside Diameter (in): | 10.00 |
| Center Hole Diameter (mm): | 59.00 |
| Center Hole Diameter (in): | 2.32 |
| Product Depth (mm): | 67.00 |
| Product Depth (in): | 2.64 |
| Product Height (mm): | 78.50 |
| Product Height (in): | 3.09 |
| Nominal Thickness (mm): | 257.00 |
| Nominal Thickness (in): | 10.12 |
| Discard Thickness (mm): | 255.80 |
| Discard Thickness (in): | 10.07 |
| Maximum Drum Diameter(mm): | 255.80 |
| Maximum Drum Discard Diameter (mm): | 255.80 |
| Actual Weight (KG): | 10.600 |
| Actual Weight (lbs): | 23.37 |
| Part Description: | Brake Drum |
| F/R: | Rear |
This product fits the following vehicles: Does not fit your vehicle? Click here to find parts for you
