Click to EnlargeUltra Plus Rotor
$169.24 each
Raybestos: 680374R
OE Number: 5C3Z2C026CA
Product Number: UP54138R
PRODUCT DESCRIPTION
Position: Rear; Right Ultra Plus Rotor
Brake Rotor
10 lug wheel
| Part Label: | Brake Rotor |
| Bolt Holes: | 10 |
| Bolt Hole Diameter (mm): | 13.00 |
| Outside Diameter (mm): | 390.00 |
| Outside Diameter (in): | 15.35 |
| Inside Diameter (mm): | 270.00 |
| Inside Diameter (in): | 10.63 |
| Center Hole Diameter (mm): | 139.50 |
| Center Hole Diameter (in): | 5.49 |
| Product Height (mm): | 124.20 |
| Product Height (in): | 4.89 |
| Nominal Thickness (mm): | 39.00 |
| Nominal Thickness (in): | 1.54 |
| Discard Thickness (mm): | 37.40 |
| Discard Thickness (in): | 1.47 |
| Mounting Bolt Circle Diameter(mm): | 163.00 |
| Mounting Bolt Hole Circle Diameter (in): | 6.42 |
| Actual Weight (KG): | 8.800 |
| Actual Weight (lbs): | 19.4 |
| Part Description: | Ultra Plus Brake Rotor (coated, cross drilled and slotted). Designed for light truck and full size SUV |
| F/R: | Rear Right |
This product fits the following vehicles: Does not fit your vehicle? Click here to find parts for you
